Hydraulic breaker

Suitable: Used for mining, demolition, construction, quarry etc;

Product Category:

Hydraulic breaker

WhatsApp:+86-15966463508

Email: dhgmachinery@donghongjixie.com

Inquire Now

Description

Suitable

Used for mining, demolition, construction, quarry etc;

It can be mounted on all common hydraulic excavator aswell as mini excavator and other carrier like skid steer loader, backhoe loader, crane, telescopic handler, wheel loader and other machinery.

Features

1.Cylinder & valves: prevents scuffing with precision finishing treatment;

2.Piston: every piston tolerance is machined perfectly according to each cylinder;

3.Chisel: 42CrMo, exceptional performance and reliability.

Product Parameters

Model	Suitable Weight	Working Pressure	Working Flow	Impact Rate	Hose Diameter	Chisel Diameter	Weight
Unit	T	kg/cm²	L/min	rpm	in	mm	kg
DHG-05	0.6-1	80-110	10-30	500-1200	1/2	34	65
DHG-10	0.8-2.5	90-120	15-30	500-1000	1/2	40	90
DHG-20	1.2-3	90-120	20-40	500-1000	1/2	45	120
DHG-30	2.5-4.5	110-140	25-40	500-900	1/2	53	170
DHG-40	6-9	95-130	30-45	450-750	1/2	68	270
DHG-43	4-7	100-130	40-80	450-950	3/4	75	380
DHG-45	7-14	130-150	45-85	400-800	3/4	85	600
DHG-50	11-16	150-170	80-110	450-630	1	100	780
DHG-70	18-26	160-180	125-150	350-600	1	135	1650
DHG-81	18-26	160-180	120-150	400-490	5/4	140	1700
DHG-121	28-32	170-190	190-250	300-400	5/4	155	2700
DHG-131	30-40	190-230	200-260	250-400	5/4	165	3000
DHG-151	37-45	200-260	210-270	230-350	5/4	175	4200
