Hydraulic quick hitch

1.Q355 Mn steel, strong durability; 2.Easy installation, high efficiency; 3.Simple & easy maintenance, less downtime; 4.CE certification obtained; 5.Suitable 1-80 ton excavator.

Product Category:

WhatsApp:+86-15966463508

Email: dhgmachinery@donghongjixie.com

Inquire Now

Description

Products Features

1.Q355 Mn steel, strong durability;

2.Easy installation, high efficiency;

3.Simple & easy maintenance, less downtime;

4.CE certification obtained;

5.Suitable 1-80 ton excavator.

Product Parameters

Model	Suitable Weight	Total Length	Total Height	Total Width	Pin Distance	Arm Width	Pin Diameter	Working Pressure	Working Flow	Weight
Unit	T	mm	mm	mm	mm	mm	mm	kg/cm²	L/min	kg
DHG-MINI	1-4	360-475	250-300	175-242	85-200	90-150	25-40	40-100	10-20	45
DHG-02	5-6	534-545	307	258-263	220-270	155-170	45-50	40-100	10-20	70
DHG-04	7-9	600	320	270-350	290-360	180-230	50-55	40-100	10-20	80
DHG-06	10-17	820	410	365-436	360-420	220-315	60-65	40-100	10-20	180
DHG-08	18-24	944-990	520	449-483	430-520	300-350	70-80	40-100	10-20	350
DHG-10	25-32	1040	600	480-540	450-560	350-410	90	40-100	10-20	550
DHG-17	33-45	1006-1173	630	550-660	500-600	370-480	100-110	40-100	10-20	750
DHG-20	46-50	1100-1200	650	650-700	550-660	480-550	110-130	40-100	10-20	900
